SpringBoot整合Flowable工作流-3(全局事件监听)

1. 前言

上一篇博客【SpringBoot整合Flowable工作流-2(代码整合) 】介绍代码整合部分。


这篇博客主要介绍 Flowable 的全局事件监听器,并且基于事件监听器实现业务的通知等业务。

2. 代码实现

2.1 实现 FlowableEventListener 接口

@Component
@Slf4j
public class FlowableBaseEventListenerImpl implements FlowableEventListener {

    @Autowired
    private FlowableTaskCreatedCallback flowableTaskCreatedCallback;
    @Autowired
    private FlowableTaskCompletedCallback flowableTaskCompletedCallback;
    @Autowired
    private FlowableInstanceFinishedCallback flowableInstanceFinishedCallback;
    @Autowired
    private FlowableInstanceDeletedCallback flowableInstanceDeletedCallback;
    //
    @Autowired
    private RuntimeService runtimeService;
    @Autowired
    private RepositoryService repositoryService;
    @Qualifier("processEngine")
    @Autowired
    private ProcessEngine processEngine;
    @Autowired
    private TaskService taskService;
    @Autowired
    protected ManagementService managementService;
    @Autowired
    protected HistoryService historyService;
    @Autowired
    private AuthHelper authHelper;

    @Override
    public void onEvent(FlowableEvent event) {
        FlowableEventType type = event.getType();
        ProcessInstanceNotifyRequestDTO requestDTO = null;
        if (type == FlowableEngineEventType.TASK_CREATED) {
            // 用户任务创建完成
            if (event instanceof org.flowable.common.engine.impl.event.FlowableEntityEventImpl) {
                org.flowable.common.engine.impl.event.FlowableEntityEventImpl eventImpl = (org.flowable.common.engine.impl.event.FlowableEntityEventImpl) event;
                TaskEntityImpl taskEntity = (TaskEntityImpl) eventImpl.getEntity();
                requestDTO = flowableTaskCreatedCallback.call(eventImpl, taskEntity);
            }
        } else if (type == FlowableEngineEventType.TASK_COMPLETED) {
            // 用户审批任务
            if (event instanceof org.flowable.engine.delegate.event.impl.FlowableEntityWithVariablesEventImpl) {
                org.flowable.engine.delegate.event.impl.FlowableEntityWithVariablesEventImpl eventImpl = (org.flowable.engine.delegate.event.impl.FlowableEntityWithVariablesEventImpl) event;
                TaskEntityImpl taskEntity = (TaskEntityImpl) eventImpl.getEntity();
                requestDTO = flowableTaskCompletedCallback.call(eventImpl, taskEntity);
            }
        } else if (type == FlowableEngineEventType.PROCESS_COMPLETED) {
            // 流程完成
            if (event instanceof org.flowable.engine.delegate.event.impl.FlowableEntityEventImpl) {
                org.flowable.engine.delegate.event.impl.FlowableEntityEventImpl eventImpl = (org.flowable.engine.delegate.event.impl.FlowableEntityEventImpl) event;
                ExecutionEntityImpl taskEntity = (ExecutionEntityImpl) eventImpl.getEntity();
                requestDTO = flowableInstanceFinishedCallback.call(eventImpl, taskEntity);
            }
        } else if (type == FlowableEngineEventType.PROCESS_CANCELLED) {
            // 流程删除
            if (event instanceof org.flowable.engine.delegate.event.impl.FlowableProcessCancelledEventImpl) {
                org.flowable.engine.delegate.event.impl.FlowableProcessCancelledEventImpl eventImpl = (org.flowable.engine.delegate.event.impl.FlowableProcessCancelledEventImpl) event;
                requestDTO = flowableInstanceDeletedCallback.call(eventImpl, null);
            }
        }
        if (requestDTO != null) {
            BpmnModel bpmnModel = repositoryService.getBpmnModel(requestDTO.getProcessDefinitionId());
            Map<String, String> dataObjectMap = bpmnModel.getMainProcess().getDataObjects().stream()
                    .collect(Collectors.toMap(v -> v.getId(), v -> v.getValue() == null ? "" : v.getValue().toString()));
            String businessNotifyUri = dataObjectMap.get(WorkflowConstants.BUSINESS_NOTIFY_URI);
            //
            log.info("processInstanceId:[{}] businessNotifyUri: [{}], requestDTO: {}",
                     requestDTO.getProcessInstanceId(),
                     businessNotifyUri,
                     JSON.toJSONString(requestDTO));
            //
            if (StringUtils.isNotEmpty(businessNotifyUri)) {
                if (businessNotifyUri.startsWith("/")) {
                    HttpServletRequest request = SpringContextUtil.getHttpServletRequest();
                    String origin = request.getHeader("gateway-forwarded-origin");
                    //
                    businessNotifyUri = origin + businessNotifyUri;
                }
                //
                ProcessInstanceNotifyRequestDTO finalRequestDTO = requestDTO;
                String finalBusinessNotifyUri = businessNotifyUri;
                String token = authHelper.getToken();
                //noinspection AlibabaAvoidManuallyCreateThread
                new Thread(() -> {
                 // TODO 以后完善为线程池异步
                    try {
                        Thread.sleep(2000);
                        // 延迟2秒
                    } catch (InterruptedException e) {
                        e.printStackTrace();
                    }
                    String data = "";
                    try (FastHttpClient httpClient = FastHttpClient.builder().build()) {
                        //
                        Map<String, String> queryMap = finalRequestDTO.toMap();
                        queryMap.put("sign", WorkflowSignerUtil.sign(WorkflowSignerUtil.mapToSignText(queryMap), finalRequestDTO.getProcessInstanceId()));
                        //
                        StringJoiner joiner = new StringJoiner("&");
                        queryMap.forEach((key, val) -> joiner.add(key + "=" + URLEncoder.ALL.encode(val == null ? "" : val, StandardCharsets.UTF_8)));
                        HttpGet httpGet = httpClient.buildGet(finalBusinessNotifyUri + "?" + joiner.toString());
                        httpGet.setHeader(Constant.TOKEN_NAME, token);
                        Response<String> response = httpClient.execute(httpGet, ResponseHandler.ofString(StandardCharsets.UTF_8));
                        data = response.getData();
                    } catch (Exception e) {
                        log.warn("", e);
                        data = e.getMessage();
                    }
                    data = StringUtils.abbreviate(data, 1000);
                    log.info("processInstanceId:[{}] notify response: {}", finalRequestDTO.getProcessInstanceId(), data);
                }).start();
            }
        }

    }

    @Override
    public boolean isFailOnException() {
        return false;
    }

    @Override
    public boolean isFireOnTransactionLifecycleEvent() {
        return false;
    }

    @Override
    public String getOnTransaction() {
        return null;
    }
}

2.2 添加全局事件监听器

@Slf4j
@Component
@Configuration
public class InitConfig implements CommandLineRunner {

    @Autowired
    private RuntimeService runtimeService;
    @Autowired
    private FlowableBaseEventListenerImpl flowableBaseEventListener;

    @Override
    public void run(String... args) {
        runtimeService.addEventListener(flowableBaseEventListener);
    }

}

3. SpringBoot整合Flowable工作流相关文章
